Product description
The reed switch contains a pair (or more) of magnetizable, flexible, metal reeds whose end portions are separated by a small gap when the switch is open. The reeds are hermetically sealed in opposite ends of a tubular glass envelope.
The reed switch application is to detect the opening of a door, when used as a proximity switch for a burglar alarm.
Specification:
| Contact Rating | 10W |
| Max. Switching Voltage | AC/DC 100V |
| Max. Switching Current | 0.5A |
| Contact Resistance | 100mΩ |
| Pull In Value(AT) | 10-35 |
| Drop Out Vaule(AT) | 5 |
| Operation Time | 1.0 mSec.(Max) |
| Release Time | 0.4 mSec.(Max) |
| Breakdown Voltage | 220VDC(AT<25) or 250VDC (AT>25) |
| Contact Capacitance | 0.7pF |
| Insulation Resistor | 10^15Ω |
| Resonant Frequency | 4KHz |
| Operation Temp. | -60℃ to +155℃ |
| Operation Frequency | 100Hz |
| Electronic Life | 10^8 (5V,10mA) |
| 10^5 (24V,400mA) | |
| Test Coil | 5000T 870Ω |
| Leads | Gold Plated |
Package Includes:
1 X MKA14103 Gold Tone Glass Tube N/O SPST Magnetic Reed Switch 2X14mm [5pcs Pack]
Note: all the descriptions and prices are subject to change without prior notice.
Free Shipping: No
Shipping Weight/Unit(g): 0.00
Std. Packing Qty. (pcs): 1
