USR-ES1 W5500 Chip SPI to LAN/ Ethernet Converter TCP/IP Module

Power supply mode:3.3V external power supply, current should be more than 200mA;

Control interface:The TTL level, 3.3V SPI interface;

PCB size: 23X25 mm;

Mechanical Dimensions:28.5X23X24mm;

USR-ES1 is the Ethernet module of a SPI interface, interface is TTL level of 3.3V, power supply voltage of +3.3V, please ensure that the current is not less than 200mA, voltage is continuous and stable +3.3V.

• High speed SPI interface 80MHz

• Hardware-TCPIP-protocol stack user built in, almost without understanding the complex network protocol knowledge

• Supports up to 8 Socket

• Support TCP, UDP, ICMP, IPv4, ARP, IGMP, PPPoE protocol

• Integration of the data link layer, physical layer

• Support the wakeup

• Support high speed serial peripheral interface (SPI model 0, 3)

• Internal 32K bytes receive buffer

• The embedded 10BaseT/100BaseTX Ethernet physical layer (PHY)

• Support auto negotiation (10/100-Based full duplex or half duplex)

• Does not support the IP patch

• The working voltage of 3.3V, I/O and 5V voltage signal

• LED display (full duplex or half duplex, network connection, network speed,active)

• Pin type package ultra small, convenient for embedded applications

• Application of C sample project

Package includes:

1 X USR-ES1 W5500 Chip SPI to LAN/ Ethernet Converter TCP/IP Module
