L298P motor shield

SKU
MTR.1003
Customer #
MOQ
10
Packaging
1pcs/lot
Unit Price
RFQ
Unit Price
from $0

Payment Accepted

Wholesale

Prices

50+ RFQ
<50 RFQ
20+ RFQ
200+ RFQ

Buyer Protection

  • Full Refund if you don't receive your order
  • Full or Partial Refund, if the item is not as described

Technical specifications:
1. The logical part of the input voltage VD: 5 v
2. The driving part of the input voltage VS: VIN input from 12 v to 6.5 v, PWRIN input from 35 v to 4.8 v
3. The logical part working current Iss: < 36 ma
4. The driving part of the working current Io: < 2 a
5. The maximum dissipation power: 25 w (T = 75 degree)
6. The control signal input level: high level < Vin < 5 V, 2.3 V low level < Vin < 0.3 V to 1.5 V
7. Working temperature: - 25 + 130 ?
8. Hardware interface: 5.0 mm spacing terminal
9. The belt buckle, and can manage access control signals
10. Drive form: dual power H bridge driver
11. A pin occupy: D4 ~ D7 direct drive motor
12. Support PWM/PLL model motor speed control
13. Size: 68 * 53 mm


Package includes:

1 X L298P Motor shields
