Reed Sensor Magnetic Switch Module Diy Kit Normally Open Magnetron Module

SKU
MDL.1336
Customer #
MOQ
10
Packaging
1pcs/lot
Unit Price
RFQ
Unit Price
from $0

Payment Accepted

Wholesale

Prices

50+ RFQ
<50 RFQ
20+ RFQ
200+ RFQ

Buyer Protection

  • Full Refund if you don't receive your order
  • Full or Partial Refund, if the item is not as described

Reed is dry reed short, is a kind of passive electronic switch contact element has a simple structure, small size and easy to control, etc., the shell is generally a sealed glass tubes are installed there are two flexible iron reed panels, also called metal rhodium has a filling of inert gas. Normally, two glass tubes made of special materials reeds are separated. When a magnetic substance near the glass tube, under the action of magnetic field lines, the two reed pipe is magnetized and attract each other contacts, the reed will pull together to make a circuit of the connected node communication. After the disappearance of the external magnetic force, two reeds separately because of their elasticity, the line also disconnected. Therefore, as a signal to control the use of magnetic field lines switching devices, the reed can be used as a sensor for counting, spacing, and so on (in the security system is mainly used for door sensor, window magnetic production), but also It is widely used in a variety of communication devices. In practice, usually with a permanent magnet control the two metal sheets turned on or not, it is also known as "magnetron."

Features:
    Imported normally open reed
    The comparator output signals clean, good waveform, driving ability, than 15mA.
    The output form: digital switching output (0 and 1)
    A fixed bolt hole for easy installation
    Small PCB board size of 3.2cm x 1.4cm
    Using a wide voltage comparator LM393
    Application: SPC exchange, copy machine, washing machines, refrigerators, camera, disinfect cupboard, door magnetic, magnetic window, electromagnetic relays, electronic weighing apparatus, level meter, gas meter, water meter.

Specification:
Working voltage of 3.3V-5V
Type:Normally-open
Comparator : LM393
Output Type : Digital output (0 and 1)
PCB board size: 3.2X1.4cm
Weight: Approx.13g


Package includes:

1 X Reed Sensor Magnetic Switch Module Diy Kit Normally Open Magnetron Module

Note: all the descriptions and prices are subject to change without prior notice.

Free Shipping: No

Shipping Weight/Unit(g): 0.00

Std. Packing Qty. (pcs): 1
